The Dispatcher Pattern

When you need to maintain multiple Python implementations that must expose identical interfaces, you face a tricky problem: how do you keep the namespaces and function signatures perfectly in sync? Today, we want to share how we solved this in Cloacina using what we call the dispatcher pattern.

The Challenge

While we’ll use Cloacina’s database backends as our example, this pattern applies to any situation where you need to maintain multiple implementations with identical interfaces. In our case, Cloacina is a workflow orchestration library written in Rust that supports both PostgreSQL and SQLite as storage backends. When creating Python bindings, we wanted to:

1. Allow users to install only the implementation they need (minimize dependencies)
2. Provide a single, consistent import interface regardless of implementation
3. Avoid runtime overhead from unused implementations
4. Make implementation selection explicit and predictable

The Dispatcher Pattern

The solution we implemented uses what we call the “dispatcher pattern” - a pure Python package that acts as a thin routing layer between the user and the actual backend implementation.

Here’s how it works:

1. Separate Packages

We have three packages:

• cloaca - The dispatcher (pure Python)
• cloaca-postgres - PostgreSQL backend (Rust extension via PyO3)
• cloaca-sqlite - SQLite backend (Rust extension via PyO3)

2. Installation via Pip Extras

Users install the package with their desired backend:

# For PostgreSQL
pip install cloaca[postgres]

# For SQLite
pip install cloaca[sqlite]

This uses pip’s “extras” feature to pull in the appropriate backend package as a dependency.

3. Dynamic Backend Loading

Let’s walk through how the dispatcher works at runtime. When a user imports the package, Python executes the module in this order:

1. Module Setup First, the module imports and initial setup:

import importlib
from typing import Any, Optional
__backend__: Optional[str] = None

2. Helper Functions Next, Python defines the helper functions (but doesn’t execute them yet):

def _validate_backend_version(module: Any, backend_name: str) -> None:
    if hasattr(module, "__version__") and module.__version__ != __version__:
        raise ImportError(f"Version mismatch: dispatcher {__version__} != {backend_name} {module.__version__}")

3. Backend Loading Logic Then, the backend loading logic is defined (before it’s used):

def _load_backend() -> tuple[Any, str]:
    available_backends = []

    # Try each backend
    for backend in ["postgres", "sqlite"]:
        try:
            module = importlib.import_module(f"cloaca_{backend}")
            _validate_backend_version(module, backend)
            available_backends.append((backend, module))
        except ImportError as e:
            if "Version mismatch" in str(e): raise
            continue

    # Select appropriate backend
    if not available_backends:
        raise ImportError("No backend installed. Install: pip install cloaca[postgres] or cloaca[sqlite]")
    # there can only be 1 backend
    if len(available_backends) > 1:
        raise ImportError(f"Multiple backends installed: {', '.join(b for b, _ in available_backends)}")

    return available_backends[0]

4. Main Execution Finally, the main execution block runs during import:

try:
    # Try to load a backend
    _backend_module, __backend__ = _load_backend()

    # Re-export all backend symbols
    __all__ = getattr(_backend_module, "__all__", [])
    for attr in __all__:
        globals()[attr] = getattr(_backend_module, attr)

    # Explicitly export common symbols
    if hasattr(_backend_module, "hello_world"):
        hello_world = _backend_module.hello_world
    if hasattr(_backend_module, "get_backend"):
        get_backend = _backend_module.get_backend

except ImportError as import_error:
    # Create placeholder functions if no backend
    def _raise_no_backend(*args, **kwargs):
        raise ImportError(str(import_error))
    hello_world = get_backend = _raise_no_backend
    __all__ = ["hello_world", "get_backend"]

This means when a user does import cloaca, the backend is already loaded and all symbols are ready to use (or error-raising placeholders are in place if no backend was found).

Here’s what happens in different scenarios:

# Happy path - PostgreSQL backend installed
>>> import cloaca
>>> cloaca.hello_world()
'Hello from Cloaca backend!'
>>> cloaca.get_backend()
'postgres'

# Happy path - SQLite backend installed
>>> import cloaca
>>> cloaca.hello_world()
'Hello from Cloaca backend!'
>>> cloaca.get_backend()
'sqlite'

# Sad path - No backend installed
>>> import cloaca
>>> cloaca.hello_world()
ImportError: No backend installed. Install: pip install cloaca[postgres] or cloaca[sqlite]

# Sad path - Version mismatch
>>> import cloaca
ImportError: Version mismatch: dispatcher 1.0.0 != postgres 1.1.0. Fix: pip uninstall cloaca cloaca-postgres && pip install cloaca[postgres]==1.0.0

# Sad path - Multiple backends installed
>>> import cloaca
ImportError: Multiple backends installed: postgres, sqlite. Use separate virtual environments.

The dispatcher ensures that:

1. Users get a clear error if no backend is installed
2. Version mismatches are caught early with helpful fix instructions
3. Multiple backends are prevented to avoid confusion
4. The API remains consistent regardless of which backend is used

Benefits of This Approach

1. Clean User Experience

Users always import from the same package:

import cloaca

# Works the same regardless of backend
workflow = cloaca.Workflow("my-workflow")

2. Minimal Dependencies

Users only install what they need. A PostgreSQL user doesn’t need SQLite libraries, and vice versa.

3. Compile-Time Optimization

Since we use conditional compilation in Rust, each backend package only contains the code it needs:

#[pymodule]
#[cfg(feature = "postgres")]
fn cloaca_postgres(m: &Bound<'_, PyModule>) -> PyResult<()> {
    // PostgreSQL-specific implementation
}

#[pymodule]
#[cfg(feature = "sqlite")]
fn cloaca_sqlite(m: &Bound<'_, PyModule>) -> PyResult<()> {
    // SQLite-specific implementation
}

4. Clear Error Messages

If no backend is installed, users get a helpful error message telling them exactly what to do.

5. Virtual Environment Isolation

The pattern naturally encourages users to use separate virtual environments for different backends, preventing configuration conflicts.

The Build System Challenge

Implementing the dispatcher pattern introduces a significant build system challenge: how do you avoid code duplication while maintaining clean separation between backends?

Our solution uses a sophisticated template-based build system that generates all configuration files and Python code from a single source. We built this using Angreal, our task automation and project templating tool that combines Python’s flexibility with Rust’s performance.

# .angreal/task_cloaca.py
@cloaca()
@angreal.command(name="generate", about="generate all configuration files from templates")
@angreal.argument(name="backend", long="backend", help="Backend to generate for: postgres or sqlite", required=True)
def generate(backend):
    """Generate all configuration files from templates."""
    try:
        version = get_workspace_version()

        project_root = Path(angreal.get_root()).parent
        template_dir = Path(angreal.get_root()) / "templates"

        # Generate dispatcher pyproject.toml
        dispatcher_template = template_dir / "dispatcher_pyproject.toml.j2"
        dispatcher_content = render_template(dispatcher_template.read_text(), {"version": version})
        dispatcher_path = project_root / "cloaca" / "pyproject.toml"

        # Generate backend Cargo.toml
        backend_template = template_dir / "backend_cargo.toml.j2"
        backend_content = render_template(backend_template.read_text(), {"backend": backend, "version": version})
        backend_path = project_root / "cloaca-backend" / "Cargo.toml"

        # Generate backend pyproject.toml
        backend_pyproject_template = template_dir / "backend_pyproject.toml.j2"
        backend_pyproject_content = render_template(backend_pyproject_template.read_text(), {"backend": backend, "version": version})
        backend_pyproject_path = project_root / "cloaca-backend" / "pyproject.toml"

        # Write files
        files_to_write = {
            dispatcher_path: dispatcher_content,
            backend_path: backend_content,
            backend_pyproject_path: backend_pyproject_content
        }

        print(f"Writing {len(files_to_write)} files...")
        for file_path, content in files_to_write.items():
            write_file_safe(file_path, content, backup=False)
            print(f"  {file_path}")

We generate our build files from templates, rendering them with version extracted from the workspace Cargo file and the selected backend. These files are intentionally clobbered regularly to maintain a clean “just-in-time” build pattern - we’ll explore this approach in depth later.

Testing Considerations

Testing becomes quite complex with this pattern. We solved it by creating ephemeral virtual environments for each test run:

def _build_and_install_cloaca_backend(backend, venv_name):
    """Build and install backend in a fresh virtualenv for testing."""
    venv = VirtualEnv(path=venv_name, now=True)
    pip = venv.path / "bin" / "pip3"
    python = venv.path / "bin" / "python"
    backend_dir = Path("cloaca-backend")

    # Install dependencies
    subprocess.run([python, "-m", "ensurepip"], check=True)
    subprocess.run([pip, "install", "maturin", "pytest"], check=True)
    subprocess.run([pip, "install", "-e", "cloaca"], check=True)

    # Build and install backend wheel
    subprocess.run([
        venv.path / "bin" / "maturin", "build",
        "--no-default-features", "--features", backend, "--release"
    ], cwd=backend_dir, check=True)
    wheel = next((backend_dir / "target" / "wheels").glob(f"cloaca_{backend}-*.whl"))
    subprocess.run([pip, "install", str(wheel)], check=True)
    return venv, python, pip

This snippet shows the core steps for building and installing a backend in an isolated environment for testing. For clarity, we’ve omitted logging, defensive checks, and cleanup logic that would be present in “production” code.

Rust Module Implementation

A minimal backend module with feature flag and exports:

use pyo3::prelude::*;

#[pyfunction]
fn hello_world() -> String {
    "Hello from Cloaca backend!".to_string()
}

#[pymodule]
#[cfg(feature = "postgres")]
fn cloaca_postgres(m: &Bound<'_, PyModule>) -> PyResult<()> {
    m.add_function(wrap_pyfunction!(hello_world, m)?)?;
    Ok(())
}

#[pymodule]
#[cfg(feature = "sqlite")]
fn cloaca_sqlite(m: &Bound<'_, PyModule>) -> PyResult<()> {
    m.add_function(wrap_pyfunction!(hello_world, m)?)?;
    Ok(())
}

This is a PyO3 implementation that compiles and binds Rust code to Python. For more details, check out the PyO3 documentation.

Version Safety and Backend Coupling

One critical aspect of the dispatcher pattern is ensuring tight coupling between the dispatcher version and backend versions to prevent runtime failures and API inconsistencies.

The Version Coupling Challenge

Since the dispatcher dynamically loads backends at runtime, there’s a risk of version mismatches:

# What happens if these versions don't match?
pip install cloaca[postgres]==1.0.0  # Installs cloaca==1.0.0 + cloaca-postgres==1.0.0
pip install cloaca-postgres==1.1.0   # Accidentally upgrades backend but not dispatcher

Our Solution: Synchronized Versioning

We enforce version synchronization through several mechanisms:

1. Exact Version Pinning in pip extras

# dispatcher pyproject.toml template
[project.optional-dependencies]
postgres = ["cloaca-postgres=={{version}}"]  # Exact version, no flexibility
sqlite = ["cloaca-sqlite=={{version}}"]

2. Runtime Version Validation

# In dispatcher __init__.py
def _validate_backend_version(backend_module, expected_version):
    """Ensure backend version matches dispatcher version."""
    backend_version = getattr(backend_module, '__version__', None)
    if backend_version != expected_version:
        raise ImportError(
            f"Backend version mismatch: expected {expected_version}, "
            f"got {backend_version}. Reinstall with 'pip install cloaca[backend]' "
            f"to ensure version compatibility."
        )

# Called during backend loading
_validate_backend_version(_backend_module, __version__)

3. Build-Time Version Consistency

Our template system ensures all packages use the same version:

# All templates receive the same version context
context = {"backend": backend, "version": version}  # From workspace Cargo.toml

API Compatibility Enforcement

Beyond version numbers, we ensure API compatibility:

1. Shared Interface Definition

# Each backend must expose the same interface
REQUIRED_BACKEND_ATTRS = ['hello_world', 'get_backend', '__backend__', '__version__']

def _validate_backend_interface(backend_module):
    """Ensure backend implements required interface."""
    missing_attrs = [attr for attr in REQUIRED_BACKEND_ATTRS
                     if not hasattr(backend_module, attr)]
    if missing_attrs:
        raise ImportError(f"Backend missing required attributes: {missing_attrs}")

Safety Implications

Version coupling failures can cause:

1. Silent API changes - Methods exist but behave differently
2. Missing functionality - New dispatcher features not available in old backends
3. Runtime crashes - Incompatible data structures or calling conventions
4. Security issues - Different validation logic between versions

Trade-offs

Benefits of tight coupling:

• Guaranteed compatibility at runtime
• Simplified testing (fewer version combinations)
• Clear error messages for version mismatches

Costs of tight coupling:

• Users can’t mix and match versions for bug fixes
• Coordinated releases required for all packages
• More complex CI/CD pipeline

When to Use This Pattern

The dispatcher pattern is ideal when:

• You have multiple implementations that are mutually exclusive (e.g., different backends, feature sets, or configurations).
• You want to minimize user dependencies by allowing them to install only what they need.
• You need compile-time optimization for each implementation.
• You want a single, consistent API regardless of the underlying implementation.

It might not be the best choice if:

• Users commonly need to switch implementations at runtime.
• The implementations are lightweight and don’t benefit from separate compilation.
• You need to support multiple implementations simultaneously in the same process.

Lessons Learned: Complexity vs. Benefits

Building this system taught us valuable lessons about when sophisticated automation makes sense versus simpler approaches. Let’s break down what we learned:

When This Approach Makes Sense

The template-based build system was worth the complexity because:

1. Scale: We needed to support multiple implementations with identical APIs
2. Maintenance: Manual duplication would lead to drift and inconsistencies
3. Testing: Complete isolation between implementations was critical
4. Distribution: We needed production-ready wheels for PyPI

When Simpler Approaches Are Better

For many projects, this would be overkill. Consider simpler alternatives if:

• You have only one implementation or implementations that don’t need isolation
• Code duplication is minimal and manageable manually
• Testing doesn’t require complete environment isolation
• You don’t need automated wheel building

The Real Cost

The sophistication came with trade-offs:

• Learning curve: New contributors need to understand the template system
• Debugging complexity: Generated files make error tracing harder, requiring composable build steps that allow for picking apart the build process
• Build dependencies: Requires angreal, Docker, and virtual environment management
• Mental overhead: Every change requires thinking about template implications
• IDE limitations: The JIT compilation approach can break modern IDE features, as build files may not exist until generated. We solved this with additional commands to generate and scrub files consistently, but it required extra effort.

Conclusion

The dispatcher pattern provides an elegant solution for Python libraries with multiple implementations or configurations, giving users a clean API while maintaining flexibility and minimizing dependencies. However, the sophisticated build system required to support it represents a significant engineering investment.

The pattern works best for libraries where:

• Implementation separation provides real value to users
• The maintenance overhead of duplication would be significant
• Clean testing isolation is important
• Distribution complexity is manageable

For simpler use cases, traditional approaches may offer better development velocity with acceptable trade-offs. The key is honestly evaluating whether the user experience benefits justify the implementation complexity.

Next time you’re building a Python library with multiple implementation options, carefully weigh these factors before choosing your approach.
